High Pressure Pumps
LMX29500
More information coming soon.
Product is built to order (3-5 business days) Minimum
$11,386.91 Including Taxes
| FREQUENCY: | 50Hz |
| RPM: | 1000rpm, 1450rpm |
| FLOW RATE: | 20L/Min (1000rpm), 29L/Min (1450rpm) |
| POWER: | 27.27HP (50Hz), 32.73HP (60Hz) |
| MAX PRESSURE: | 7251.89Psi |
| OIL CAPACITY: | 3.1Lt |
| MAX TEMP: | 65ºC |
| INLET: | G 3/4” |
| OUTLET: | G 1/2” |
| SHAFT: | 80mmL x 40Ø Shaft |
| PISTON: | 20mm |
| Approx Weight: | 60Kg |
More Information
- Forged pump head designed for strength
- ATEX 2 Certified
- Cam-Ground pistons for smoother stroke and better oil-tightness
- Oversized shaft and long end section for better torque transmission
- Extra-thick ceramic pistons for greater durability
- Double gasket sealing system
- Intake and delivery valves with larger water passages
- Tapered roller bearings with high resistance
- Body of the pump designed for long-term durability
- Rods made of a special anti-friction alloy
Customer Testimonials
Coming Soon.
Video Guides
Coming Soon.
| Weight | 60 kg |
|---|---|
| Shaft Position | Right |
